PILE INTEGRITY TESTING LAB IN BHOPAL

Pile Integrity Testing (PIT) is a fast and effective technique to verify the soundness of deep
foundations. This test, often performed for bridge piers and building foundations, utilizes stress waves to detect defects such as cracks or changes in material density. Our Pile Integrity
Testing Lab in Bhopal is equipped with the latest PIT equipment, providing quick and accurate
assessments for various construction projects.

Why Pile Integrity Testing is Important:

  • Detects flaws early in construction to prevent
    future failures.
  • Provides a non-invasive assessment of piles.
  • Helps determine the depth and quality of installed
    piles.

Technical Parameters

  • Pile Length: Up to 50 meters.
  • Impact Device:2 kg to 5 kg hammer.
  • Sensor Type: Accelerometers or geophones.
  • Test Frequency:2 Hz to 10 kHz.
  • Standards: Follows ASTM D5882.

PIT Applications:

  • Quality assurance for newly installed piles.
  • Assessment of existing structures for renovation.
  • Suitable for all pile types including bored, driven,
    and CFA piles.

PLATE LOAD TESTING LAB IN BHOPAL

Plate Load Testing Lab in Bhopal is essential in determining soil strength and settlement
behavior under load conditions, crucial for construction and geotechnical engineering projects.
This test, standardized under IS: 1888, provides accurate data on soil bearing capacity for
foundation design. At our lab, we ensure compliance with industry standards and use
advanced hydraulic jacks and load cells for precise data collection. Our testing process covers
a variety of soil types including clay, silt, and granular soils, providing detailed analysis for
infrastructure projects in Bhopal and beyond.

Benefits of Plate Load Testing

  • Accurate assessment of soil conditions
  • Reduction in construction risks.
  • Helps optimize foundation design, minimizing costs.

Technical Parameters

  • Plate Size: Typically 300 mm to 750 mm in diameter.
  • Load Range: Up to 100 kN, depending on soil conditions.
  • Settlement Measurement Accuracy: ±0.1 mm.
  • Loading Equipment: Hydraulicjacks with
    controlled increments.
  • Test Duration: Generally 1-2 hours per load step, depending on soil type.

Common Applications

  • Pavements and highways.
  • Foundation designs for buildings.
  • Load-bearing calculations for bridges and industrial structures.

EV2 TESTING LAB IN BHOPAL

EV2 Testing is a critical test in the field of geotechnical engineering, particularly for road
construction and pavement design. The EV2 test measures the deformation modulus of soil,
providing essential data on soil compaction quality. At our EV2 Testing Lab in Bhopal, we
adhere to international standards, ensuring accuracy and reliability. Our high-precision
sensors and hydraulic loading systems capture precise data, helping engineers make informed
decisions about soil behavior under stress.

Advantages of EV2 Testing

  • Verification of soil compaction.
  • Enhances pavement durability and reduces maintenance costs.
  • Ensures compliance with road construction standards.

Technical Parameters

  • Plate Size: Commonly 300 mm.
  • Load Range: Hydraulic or mechanical jacks.
  • Deformation Range: Up to 10 mm.
  • Testing Standards: Follows DIN 18134.
  • Test Duration: 10-15 minutes per load step.

Applications in Construction

  • Roadbeds for highways.
  • Airport runways.
  • Industrial and commercial construction
    foundations.
